Range Rover P38
78
SEATS
NEW RANGE ROVER
36
REPAIR
Refit
6. Clean lever pivot and smear with grease.
7. Position motor assembly and locate operating
rod to lever. Fit new spring clip.
8. Align motor and fit new roll pin.
9. Connect multiplug and secure to bracket.
10. Fit seat.
See this section.
LATCH REAR SEAT
Service repair no - 78.80.12
Remove
1. Fold adjacent seat forward.
2. Remove 3 screws securing latch cover. Remove
cover.
3. Slacken seat belt stalk bolt.
4. Remove 4 screws securing latch to seat
assembly. Remove latch.
NOTE: Fold top of latch forward to release.
5. Remove bolt securing seat belt stalk. Remove
stalk.
