Automatic gearbox - EM-CVTHose/pipe - feed - intermediate to fluid cooler

HOSE/PIPE - FEED - INTERMEDIATE TO FLUID COOLER

Service repair no - 44.24.26

Remove

  1. Raise front of vehicle.

WARNING: Support on safety stands.

  1. Remove bonnet locking platform. See BODY, Exterior fittings.
  2. Position container underneath gearbox fluid cooler connections to collect any spillage.
Hose/pipe - feed - intermediate to fluid cooler – Position container underneath gearbox fluid cooler connections to collect any spillage.
  1. Remove bolt securing cooler pipe connection to fluid cooler.
  2. Release connection from cooler and discard ’O’ ring.
  3. Remove release catch, refit in reverse position and release hose from intermediate pipe.
  4. Refit release catch in safe position.
  5. Remove pipe clamp clip, release pipe from clamp and remove pipe.

CAUTION: Plug the connections.

Refit

  1. Clean pipe end and mating faces.
  2. Connect hose to intermediate pipe.
  3. Using new ’O’ ring, align pipe to fluid cooler, fit bolt and tighten to 10 Nm.
  4. Position pipe in clamp and secure clamp clip.
  5. Fit bonnet locking platform. See BODY, Exterior fittings.
  6. Top-up gearbox fluid level. See MAINTENANCE.
  7. Remove stand(s) and lower vehicle.
