ABS LOCATION COMPONENTS
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C012 | ABS front earth | |
| C020 | Passenger dashboard earth | |
| D001 | Front/dashboard coupling | |
| E050 | Instrument panel | 5560B |
| H001 | Ignition switch | 5520A |
| I030 | Brake pedal switch | 5550D |
| K020 | Left brake pad wear sensor (switch) | 3310A |
| K021 | Right brake pad wear sensor (switch) | 3310A |
| K025 | Brake fluid level sensor (switch) | |
| K070 | Left front wheel sensor for ABS | 3340A |
| K071 | Right front wheel sensor for ABS | 3340A |
| K075 | Left rear wheel sensor for ABS | 3340A |
| K076 | Right rear wheel sensor for ABS | 3340A |
| M001 | Body computer | 5505A |
| M010 | Engine management control unit | 1060G |
| M050 | ABS control unit | 3340A |
| M140 | Warning lights and milometer control unit (NSO) | |
| R010 | Multiple diagnostic coupling |
