ESP COMPONENT LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
A001	BATTERY
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B005	MAXI FUSE BOX
B098	ADDITIONAL FUSE BOX
C010	LEFT FRONT EARTH
C011	RIGHT FRONT EARTH
C012	ABS FRONT EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
D001	FRONT/DASHBOARD COUPLING
D006	FRONT/REAR COUPLING
E050	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	Ignition switch	Op. 5520A IGNITION SWITCH
I030	BRAKE PEDAL SWITCH	Op. 5550D BRAKE AND REVERSING LIGHTS
I031	CLUTCH PEDAL SWITCH
I035	Safety switch on brake pedal for cruise control
I115	STABILITY CONTROL SYSTEM SWITCH
K020	LEFT BRAKE PAD WEAR SENSOR (SWITCH)	Op. 3310A FRONT DISC BRAKES
K021	RIGHT BRAKE PAD WEAR SENSOR (SWITCH)	Op. 3310A FRONT DISC BRAKES
K025	BRAKE FLUID LEVEL SENSOR (SWITCH)
K070	LEFT FRONT WHEEL SENSOR FOR ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K071	RIGHT FRONT WHEEL SENSOR FOR ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K075	LEFT REAR WHEEL SENSOR FOR ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K076	RIGHT REAR WHEEL SENSOR FOR ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT CONTROL UNIT	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
M050	ABS CONTROL UNIT	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
M80	CENTRAL DOOR LOCKING CONTROL UNIT
M091	SLEWING CONTROL UNIT
M093	STEERING WHEEL NODE CONTROL UNIT (NVO)	Op. 5550A STALK UNIT
M140	WARNING LIGHTS AND MILOMETER CONTROL UNIT (NSO)
R010	MULTIPLE DIAGNOSTIC COUPLING
