Wiring diagrams and electrical functionsCode location components
CODE LOCATION COMPONENTS
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| C015 | Driver''s dashboard earth | |
| D001 | Front/dashboard coupling | |
| D020 | Dashboard/rear coupling | |
| H001 | Ignition switch | 5520A |
| M001 | Body computer | 5505A |
| M010 | Engine management control unit | 1060G |
| M050 | ABS control unit | 3340A |
| M093 | Steering wheel node control unit (NVO) | 5550A |
| P091 | Aerial for CODE | 5580E |
