CODE COMPONENT LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C015	DRIVER''S DASHBOARD EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
D006	FRONT/REAR COUPLING
D020	DASHBOARD/REAR COUPLING
H001	Ignition switch	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT CONTROL UNIT	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
M093	STEERING WHEEL NODE CONTROL UNIT (NVO)	Op. 5550A STALK UNIT
P091	AERIAL FOR FIAT-CODE	Op. 5580E ANTI-THEFT DEVICE
