AIR BAG COMPONENTS LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C015	DRIVER''S DASHBOARD EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
C050	AIR BAG SYSTEM EARTH
D020	DASHBOARD/REAR COUPLING
D070	DRIVER''S SEAT COUPLING
D071	PASSENGER SEAT COUPLING
E050	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	Ignition switch	Op. 5,520A IGNITION SWITCH
H075	PASSENGER AIR BAG DISABLING SWITCH	Op. 5580C AIR BAG SYSTEM
I046	DRIVER''S SEAT BELT SWITCH
I047	PASSENGER SEAT BELT SWITCH
K066	SENSOR FOR DRIVER''S SIDE BAG	Op. 5580C AIR BAG SYSTEM
K067	SENSOR FOR PASSENGER SIDE BAG	Op. 5580C AIR BAG SYSTEM
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M060	AIR BAG CONTROL UNIT	Op. 5580C AIR BAG SYSTEM
M093	STEERING WHEEL NODE CONTROL UNIT (NVO)	Op. 5550A STALK UNIT
M140	WARNING LIGHTS AND MILOMETER CONTROL UNIT (NSO)
Q009	DRIVER''S AIR BAG	Op. 5580C AIR BAG SYSTEM
Q011	AIR BAG IN DASHBOARD (PASSENGER SIDE)	Op. 5580C AIR BAG SYSTEM
Q020	DRIVER''S SIDE FRONT BELT PRETENSIONER	Op. 7065A FRONT SAFETY BELTS
Q021	PASSENGER SIDE FRONT BELT PRETENSIONER	Op. 7065A FRONT SAFETY BELTS
Q022	DRIVER''S SIDE REAR SEAT BELT PRETENSIONER	Op. 7065B REAR SAFETY BELTS
Q023	PASSENGER SIDE REAR SEAT BELT PRETENSIONER	Op. 7065B REAR SAFETY BELTS
Q030	DRIVER''S SIDEBAG	Op. 5580C AIR BAG SYSTEM
Q031	PASSENGER SIDEBAG	Op. 5580C AIR BAG SYSTEM
Q040	DRIVER''S HEAD BAG
Q041	PASSENGER HEAD BAG
