AUTOMATIC TRANSMISSION COMPONENT LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
A001	BATTERY	Op. 5530B BATTERY AND LEADS
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTIFUNCTION COMPONENTS
B005	MAXI FUSE BOX
B098	ADDITIONAL FUSE BOX
C010	LEFT FRONT EARTH
C011	RIGHT FRONT EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
D001	FRONT/DASHBOARD COUPLING
D006	FRONT/REAR COUPLING
D020	DASHBOARD/REAR COUPLING
E050	INSTRUMENT PANEL	Op. 5,560B ANALOGUE INSTRUMENT PANEL
H001	Ignition switch	Op. 5520A IGNITION SWITCH
H037	GEAR CONTROLS
I030	BRAKE PEDAL SWITCH	Op. 5550D BRAKE AND REVERSING LIGHTS
J007	GEAR LEVER LOCK ACTUATOR RELAY FEED
L050	AUTOMATIC TRANSMISSION SOLENOID VALVES
L058	AUTO. TRANS. LEVER LOCKING SOLENOID
M001	BODY COMPUTER	Op. 5505A MULTIFUNCTION COMPONENTS
M055	AUTOMATIC TRANSMISSION CONTROL UNIT
M140	WARNING LIGHTS AND MILOMETER CONTROL UNIT (NSO)
R010	MULTIPLE DIAGNOSTIC COUPLING
