Code wiring diagram

Make

Fiat

Model

Ulysse Factory Service Manual

Year

2002–2010

Section

Vehicle electronic systems › Code wiring diagram

Wiring diagrams and electrical functionsCode wiring diagram

CODE WIRING DIAGRAM

Wiring Diagram

Components

Component code	Description	Reference to the assembly
See B001 ENGINE COMPARTMENT JUNCTION UNIT	Engine compartment junction unit	5505A
See C015 DRIVER'S DASHBOARD EARTH	Driver''s dashboard earth
See D001 FRONT/DASHBOARD COUPLING	Front/dashboard coupling
See D020 DASHBOARD/REAR COUPLING	Dashboard/rear coupling
See H001 Ignition switch	Ignition switch	5520A
See M001 BODY COMPUTER	Body computer	5505A
See M010 ENGINE MANAGEMENT CONTROL UNIT	Engine management control unit	1060G
See M050 ABS CONTROL UNIT	ABS control unit	3340A
See M093 STEERING WHEEL NODE CONTROL UNIT (NVO)	Steering wheel node control unit (NVO)	5550A
See P091 AERIAL FOR FIAT-CODE	Aerial for CODE	5580E

2.0 16V JTD, 2.2 16V JTD · MY 2005

Components

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C015	DRIVER''S DASHBOARD EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
D006	FRONT/REAR COUPLING
D020	DASHBOARD/REAR COUPLING
H001	Ignition switch	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT CONTROL UNIT	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
M093	STEERING WHEEL NODE CONTROL UNIT (NVO)	Op. 5550A STALK UNIT
P091	AERIAL FOR FIAT-CODE	Op. 5580E ANTI-THEFT DEVICE
