Alarm location components
- Make
- Fiat
- Model
- Ulysse Factory Service Manual
- Year
- 2002–2010
- Section
- Vehicle electronic systems › Alarm location components
Wiring diagrams and electrical functionsAlarm location components
ALARM LOCATION COMPONENTS
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| C011 | Right front earth | |
| C020 | Passenger dashboard earth | |
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| D001 | Front/dashboard coupling | |
| D030 | Left front door coupling | |
| D031 | Right front door coupling | |
| D085 | Rear/tailgate coupling | |
| E040 | Alarm LED | |
| I010 | Bonnet release switch | |
| I011 | Boot release switch | 7015B |
| I018 | Switch on left rear door | |
| I019 | Switch on right rear door | |
| I130 | Volumetric sensors disabling switch | |
| K060 | Volumetric sensor for left alarm | |
| K061 | Volumetric sensor for right alarm | |
| M001 | Body computer | 5505A |
| M030 | Alarm control unit | |
| N050 | Left front door lock geared motor | 7005N |
| N051 | Right front door lock geared motor | 7005N |
| N057 | Boot lock geared motor | |
| P090 | Alarm siren |
