ESP LOCATION COMPONENTS

Location Components

Components

Component code	Description	Reference to the assembly
B001	Engine compartment junction unit	5505A
C010	Left front earth
C011	Right front earth
C012	ABS front earth
C020	Passenger dashboard earth
D001	Front/dashboard coupling
D020	Dashboard/rear coupling
E050	Instrument panel	5560B
H001	Ignition switch	5520A
I030	Brake pedal switch	5550D
I115	Stability control system switch
K020	Left brake pad wear sensor (switch)	3310A
K021	Right brake pad wear sensor (switch)	3310A
K025	Brake fluid level sensor (switch)
K070	Left front wheel sensor for ABS	3340A
K071	Right front wheel sensor for ABS	3340A
K074	Slewing sensor (VDC)
K075	Left rear wheel sensor for ABS	3340A
K076	Right rear wheel sensor for ABS	3340A
M001	Body computer	5505A
M010	Engine management control unit	1060G
M050	ABS control unit	3340A
M093	Steering wheel node control unit (NVO)	5550A
M140	Warning lights and milometer control unit (NSO)
R010	Multiple diagnostic coupling
