ALARM COMPONENT LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5,505A MULTIFUNCTION COMPONENTS
C011	RIGHT FRONT EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
C030	LEFT REAR EARTH
C031	RIGHT REAR EARTH
D001	FRONT/DASHBOARD COUPLING
D030	DRIVER''S FRONT DOOR COUPLING
D031	PASSENGER FRONT DOOR COUPLING
D085	REAR/TAILGATE COUPLING
E040	ALARM LED
I010	BONNET RELEASE SWITCH
I011	BOOT RELEASE SWITCH	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I018	SWITCH ON LEFT REAR DOOR
I019	SWITCH ON RIGHT REAR DOOR
I130	VOLUMETRIC SENSORS DISABLING SWITCH
K060	VOLUMETRIC SENSOR FOR LEFT ALARM
K061	VOLUMETRIC SENSOR FOR RIGHT ALARM
M001	BODY COMPUTER	Op. 5,505A MULTIFUNCTION COMPONENTS
M030	ALARM CONTROL UNIT
N050	LEFT FRONT DOOR LOCK GEARED MOTOR
N051	RIGHT FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N057	BOOT LOCK GEARED MOTOR
