Lower finisher - windscreen Repairs
EXTERIOR FITTINGS
REPAIRS 76-2-17
Lower finisher - windscreen
$% 76.43.41
Remove
1. Remove RH windscreen side finisher.
2. Remove both wiper arms.
3. Using LRT-99-500A remove aluminium boss
from both wiper spindles and discard.
4. Remove plastic inserts from both wiper
spindles.
5. Release both drain tubes from underside of
finisher.
6. Release clips and carefully position finisher
away from wiper spindles.
7. Slide lower windscreen finisher away from LH
side finisher and remove.
Refit
1. Position lower finisher beneath LH side finisher
and secure with clips.
2. Fit both drain tubes to finisher.
3. Position plastic inserts to wiper spindles.
4. Fit new aluminium boss to both wiper spindles.
5. Fit wiper arms.
6. Fit RH windscreen side finisher.
M76 4362
LRT-99-500A
