L322 Range Rover Service Procedures
EXTERIOR FITTINGS
REPAIRS
76-2-7
Refit
1. Fit foam pad to cheater panel.
2. Feed mirror harness through panel, position
mirror, fit and tighten Torx screws to 10 Nm (7
lbf.ft).
3. Fit and secure upper door trim finisher.
4. Fit front door trim casing.
Tow bar
$% 76.11.41
Remove
1. Remove bumper armature.
2. Remove tow ball locking pin.
3. Remove nut and bolt securing tow ball to tow
bar. Remove the tow ball.
4. Remove 2 bolts securing socket to tow bar and
position the socket aside.
