Range Rover P38
70
BRAKES
NEW RANGE ROVER
24
REPAIR
STOP LIGHT SWITCH - FROM 99MY
Service repair no - 70.35.42
1. Remove closing panel from fascia.
See
CHASSIS AND BODY, Repair.
2. Remove screw and remove heater outlet duct.
3. Remove 4 scrivets and remove access panel
from fascia.
4. Release and remove heater air duct for access
to stop light switch.
5. Disconnect multiplug from stop light switch.
6. Remove stop light switch from pedal bracket.
Refit
7. Ensure new stop light switch plunger is fully
extended for initial setting.
8. Fit stop light switch to pedal bracket and connect
multiplug.
9. Fit heater air duct.
10. Fit access panel and secure with scrivets.
11. Fit heater outlet duct and secure with screw.
12. Fit closing panel to fascia.
See CHASSIS AND
BODY, Repair.
