Range Rover P38
SEATS
9
REPAIR
2. RH seat: Remove fuse cover from seat base
finisher. Remove 3 fixings and 1 screw securing
finisher. Remove finisher.
3. Remove 3 fixings securing rear outer base
finisher to seat mounting bracket. Remove
finisher.
4. Remove 4 fixings securing rear inner seat base
finisher to seat mounting bracket. Remove
finisher.
5. Remove bolt securing seat belt to seat. Release
seat belt from seat.
6. Remove 4 Torx bolts securing seat to seat
mounting brackets.
7. Release seat from mountings for access to seat
base.
