Wiring diagrams and electrical functionsInstrument panel - wiring diagram

INSTRUMENT PANEL - WIRING DIAGRAM

1.2 8v

WIRING DIAGRAM

COMPONENTS

Component Code	Description	Reference to the operation
A001	BATTERY	Op. 5530B10 BATTERY - R+R
B001	JUNCTION UNIT	Op. 5505A10 JUNCTION UNIT - R+R
C010	LEFT FRONT EARTH
C015	DASHBOARD EARTH, DRIVER'S SIDE
D004	FRONT/ENGINE COUPLING
E050	INSTRUMENT PANEL	Op. 5560B10 CONTROL PANEL - R+R
H001	IGNITION SWITCH	Op. 5520A10 IGNITION SWITCH ASSEMBLY - R+R
I040	HANDBRAKE SWITCH	Op. 5550D18 HANDBRAKE ON WARNING LIGHT SWITCH - R+R
K020	LEFT BRAKE PAD WEAR SENSOR (SWITCH)	Op. 3310A30 FRONT BRAKE CALIPER (ONE) - R.R
K025	BRAKE FLUID LEVEL SENSOR (SWITCH)	Op. 3330C30 BRAKE FLUID RESERVOIR - R + R AND WASH INSIDE
K030	ENGINE OIL PRESSURE SENSOR (SWITCH)	Op. 1084A42 ENGINE OIL PRESSURE WARNING LIGHT SWITCH - R + R
K036	ENGINE COOLANT TEMPERATURE SENSOR/SENDER UNIT	Op. 1088E30 SWITCH FOR WATER TEMPERATURE WARNING LIGHT - R.R.
K046	RPM SENSOR	Op. 5510C26 ENGINE RPM SENSOR - R+R
M001	BODY COMPUTER	Op. 5505A32 BODY COMPUTER - R.R
M010	ENGINE MANAGEMENT ECU	Op. 1056B82 INJECTION/IGNITION SYSTEM E.C.U. (ONE) - R + R
M051	Braking system control unit	Op. 3340A12 ABS HYDRAULIC AND ELECTRONIC CONTROL UNIT - R.R.
N040	FUEL PUMP AND LEVEL GAUGE	Op. 1040A70 SUBMERGED PUMP ASSEMBLY COMPLETE WITH LEVEL GAUGE CONTROL - R + R

1.4 16v

WIRING DIAGRAM

COMPONENTS

Component Code	Description	Reference to the operation
A001	BATTERY	Op. 5530B10 BATTERY - R+R
B001	JUNCTION UNIT	Op. 5505A10 JUNCTION UNIT - R+R
C010	LEFT FRONT EARTH
C015	DASHBOARD EARTH, DRIVER'S SIDE
E050	INSTRUMENT PANEL	Op. 5560B10 CONTROL PANEL - R+R
H001	IGNITION SWITCH	Op. 5520A10 IGNITION SWITCH ASSEMBLY - R+R
I040	HANDBRAKE SWITCH	Op. 5550D18 HANDBRAKE ON WARNING LIGHT SWITCH - R+R
K020	LEFT BRAKE PAD WEAR SENSOR (SWITCH)	Op. 3310A30 FRONT BRAKE CALIPER (ONE) - R.R
K025	BRAKE FLUID LEVEL SENSOR (SWITCH)	Op. 3330C30 BRAKE FLUID RESERVOIR - R + R AND WASH INSIDE
K030	ENGINE OIL PRESSURE SENSOR (SWITCH)	Op. 1084A42 ENGINE OIL PRESSURE WARNING LIGHT SWITCH - R + R
K036	ENGINE COOLANT TEMPERATURE SENSOR/SENDER UNIT	Op. 1088E30 SWITCH FOR WATER TEMPERATURE WARNING LIGHT - R.R.
K046	RPM SENSOR	Op. 5510C26 ENGINE RPM SENSOR - R+R
M001	BODY COMPUTER	Op. 5505A32 BODY COMPUTER - R.R
M010	ENGINE MANAGEMENT ECU	Op. 1056B82 INJECTION/IGNITION SYSTEM E.C.U. (ONE) - R + R
M051	Braking system control unit	Op. 3340A12 ABS HYDRAULIC AND ELECTRONIC CONTROL UNIT - R.R.
N040	FUEL PUMP AND LEVEL GAUGE	Op. 1040A70 SUBMERGED PUMP ASSEMBLY COMPLETE WITH LEVEL GAUGE CONTROL - R + R

1.3 Multijet

WIRING DIAGRAM

COMPONENTS

Component Code	Description	Reference to the operation
A001	BATTERY	Op. 5530B10 BATTERY - R+R
B001	JUNCTION UNIT	Op. 5505A10 JUNCTION UNIT - R+R
C010	LEFT FRONT EARTH
C015	DASHBOARD EARTH, DRIVER'S SIDE
E050	INSTRUMENT PANEL	Op. 5560B10 CONTROL PANEL - R+R
H001	IGNITION SWITCH	Op. 5520A10 IGNITION SWITCH ASSEMBLY - R+R
I040	HANDBRAKE SWITCH	Op. 5550D18 HANDBRAKE ON WARNING LIGHT SWITCH - R+R
K020	LEFT BRAKE PAD WEAR SENSOR (SWITCH)	Op. 3310A30 FRONT BRAKE CALIPER (ONE) - R.R
K025	BRAKE FLUID LEVEL SENSOR (SWITCH)	Op. 3330C30 BRAKE FLUID RESERVOIR - R + R AND WASH INSIDE
K030	ENGINE OIL PRESSURE SENSOR (SWITCH)	Op. 1084A42 ENGINE OIL PRESSURE WARNING LIGHT SWITCH - R + R
K036	ENGINE COOLANT TEMPERATURE SENSOR/SENDER UNIT	Op. 1060G14 ENGINE COOLANT TEMPERATURE SENSOR - R.R.
K046	RPM SENSOR	Op. 1060G20 ENGINE RPM SENSOR - R.R.
K101	FUEL TEMPERATURE AND WATER IN FUEL FILTER SENSOR	Op. 1044B10 FUEL FILTER ASSEMBLY - R + R OR REPLACE
M001	BODY COMPUTER	Op. 5505A32 BODY COMPUTER - R.R
M010	ENGINE MANAGEMENT ECU	Op. 1060G80 DIESEL ELECTRONIC INJECTION CONTROL UNIT - R.R
M051	Braking system control unit	Op. 3340A12 ABS HYDRAULIC AND ELECTRONIC CONTROL UNIT - R.R.
N040	FUEL PUMP AND LEVEL GAUGE	Op. 1040A70 SUBMERGED PUMP ASSEMBLY COMPLETE WITH LEVEL GAUGE CONTROL - R + R
