13. Disconnect breather hose from inlet plenum. 21. Collect upper inlet manifold gasket.
14. Remove bolt securing coolant rails.
15. Release engine harness from bulkhead clips Refit and position aside.
16. Remove 4 bolts securing ignition coils and position ignition coils aside.

10. Connect breather hose to inlet plenum.
11. Connect brake servo vacuum pipe to inlet
12. Connect EVAP pipe to inlet plenum.
13. Position coolant hoses to throttle body and
14. Fit breather hose to throttle body and secure
15. Connect multiplug to throttle body.
16. Connect throttle and cruise control cables and
17. Release plug leads from upper manifold clips.
17. Adjust throttle and cruise control cables.
18. Disconnect multiplug from IACV.
19. Release and disconnect IACV hose.

18. Connect air intake hose and tighten clips.
19. Top-up cooling system
20. Fit bonnet.
21. Connect battery earth lead.
22. Fit battery cover and secure with fixings.
20. Remove 6 bolts securing upper inlet manifold and remove upper inlet manifold.
1. Clean upper and lower inlet manifold mating faces, dowels and dowel holes.
2. Using a new gasket, position upper inlet manifold. Fit bolts and, working in a diagonal sequence, tighten to 22 Nm (16 lbf.ft).
3. Connect hose and multiplug to TP sensor.
4. Connect hose and multiplug to IACV. Secure hose with clip.
5. Secure ht leads to upper inlet manifold.
6. Position ignition coils, fit bolts and tighten to 8 Nm (6 lbf.ft).
7. Ensure clip under ignition coils is located on fuel pipe.
8. Secure engine harness in bulkhead clips.
9. Fit coolant rail bolt and tighten to 22 Nm (16 lbf.ft).

plenum.

secure hose clips.

clip.

secure in throttle body cams.
