L322 Range Rover Service Procedures
INTERIOR FITTINGS
76-3-14 REPAIRS
3. Position shroud to carrier, fit and secure with
clips and screws.
4. Fit drivers side lower trim finisher.
Finisher - lower - drivers side.
5. Fit drivers side upper trim finisher.
Finisher - upper - drivers side.
6. Fit centre air vent.
REPAIRS, Ventilator(s) - centre.
7. Fit glove box.
8. Fit rotary coupler.
Closing panel - fascia end
$% 76.46.11
Remove
1. Release sufficient door aperture seal to access
closing panel.
2. Release 3 clips securing end closing panel to
fascia and carefully remove panel.
NOTE: Do not carry out further dismantling if
component is removed for access only.
3. Remove 3 retaining clips from closing panel.
Refit
1. Fit retaining clips to closing panel.
2. Position closing panel to fascia, align and
secure clips.
3. Fit seal to door aperture.
