INTERIOR FITTINGS
REPAIRS 76-3-21
14. Fit clip securing harness to footwell duct.
15. Fit clip securing cassette/CD harness.
16. Connect solar sensor multiplug.
17. Fit clip securing instrument pack harness.
18. Fit and secure steering column gaiter.
19. Fit instrument pack lower finisher.
20. Fit instrument pack.
21. Fit cassette/CD unit.
ENTERTAINMENT, REPAIRS, Cassette/CD
unit.
22. Fit footwell closing panels.
Closing panel - centre console.
23. Fit air suspension control panel.
Switch panel - air suspension.
24. Fit passenger airbag.
25. Fit centre console.
Fascia - remove for access & refit
$% 76.46.23.99
This procedure shows how to position the fascia
aside for access. The fascia is released from the
passenger side and swung aside for access, with the
main harness still attached to the fascia.
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Make the SRS system safe.
Supplementary Restraint System (SRS)
Precautions.
2. Drain coolant.
ADJUSTMENT, Coolant - drain and refill.
3. Recover refrigerant from A/C system.
RECOVERY, RECYCLING AND
RECHARGING, Refrigerant recovery -
recycling and recharge.
4. Remove air intake plenum.
5. Remove front seats.
6. Remove heater control panel.
REPAIRS, Controls - heater (ECU).
7. Remove air suspension control panel.
Switch panel - air suspension.
8. Remove handbrake lever assembly.
BRAKES, REPAIRS, Lever assembly
9. Remove footwell closing panels.
Closing panel - centre console.
10. Release and remove air ducts from HEVAC
assembly.
11. LHD only: Remove drivers footrest.
12. Remove 'A' post lower finisher.
Trim finisher - 'A' post - lower.
13. Remove 'A' post upper finishers.
