L322 Range Rover Service Procedures
PANEL REPAIRS
REPAIRS
-35
12. Fit SRS side crash sensor.
13. Fit front and rear doors.
14. Fit rear road wheel.
15. Connect alternator.
16. Connect battery earth lead.
Body side panel - sill and 'B/C' post
section
In this procedure the sill and 'B/C' post section of the
body side panel is changed.
Remove
1. Disconnect battery earth lead.
2. Disconnect alternator.
3. Remove all components that are removed on
the sill section of the body side panel.
, , Body side panel - sill section.
4. Remove headlining.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
