L322 Range Rover Service Procedures
PANEL REPAIRS
-46
REPAIRS
Roof assembly
Remove
1. Disconnect battery earth lead.
2. Disconnect alternator.
3. Remove front screen.
4. Remove tail door upper.
5. Remove tail door aperture seal.
6. Remove both front seats.
7. Remove rear seat cushion.
8. Remove headlining.
9. Remove sunroof.
10. Remove vehicle harnesses from all roof areas.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
Refit
1. Fit vehicle harnesses to all roof areas.
2. Fit sunroof.
3. Fit front screen.
4. Fit tail door upper.
5. Fit tail door aperture seal.
6. Fit headlining.
7. Fit rear seat cushion.
8. Fit both front seats.
9. Connect alternator.
10. Connect battery earth lead.
