L322 Range Rover Service Procedures
PANEL REPAIRS
REPAIRS
-47
Doors
The doors are serviced as complete assemblies. The
door skins cannot be serviced separately.
Remove
1. Remove door.
Repair
1. The doors are made from Aluminium. The door
inner assemblies are made up of pressed
panels and die cast panels, which are joined
together using a combination of riveting and
bonding.
CAUTION: The shaded areas in the above
illustration highlight the cast aluminium
panels. These panels cannot not be
repaired, if damage occurs to these panels
then the whole door must be replaced.
Refit
1. Fit door.
M77 2221A
