L322 Range Rover Service Procedures
PANEL REPAIRS
REPAIRS
-37
Refit
1. Fit all components that are removed on the sill
and 'B/C' post section of the body side panel.
, , Body side panel - sill section.
2. Connect alternator.
3. Connect battery earth lead.
Sill reinforcement
In this procedure the sill and 'B/C' post section of the
body side panel is changed.
Remove
1. Disconnect battery earth lead.
2. Disconnect alternator.
3. Remove all components that are removed on
the sill section of the body side panel.
, , Body side panel - sill section.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
If the 'B/C' post reinforcement is not being
replaced then the sill reinforcement must be cut
in the area identified by arrow A.
Refit
1. Fit all components that are removed on the sill
and 'B/C' post section of the body side panel.
, , Body side panel - sill section.
2. Connect alternator.
3. Connect battery earth lead.
M77 2226
A
