L322 Range Rover Service Procedures
PANEL REPAIRS
REPAIRS
-45
Floor longitudinal
The floor longitudinal closing panel may also be
changed with the floor longitudinal closing panel.
Remove
1. Disconnect battery earth lead.
2. Disconnect alternator.
3. Remove heat shield from spare wheel well.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
The panel must be cut rearward of the arrow
'A'. Cutting the panel forward of this mark
will structurally weaken the body.
Refit
1. Fit heat shield to spare wheel well.
2. Connect alternator.
3. Connect battery earth lead.
