Rover 200/400 Coupé, Cabriolet & Tourer Workshop Manual Supplement21 · Heating & ventilation
21 · Heating & A/C

Blower assembly motor

Make
Rover
Model
Coupé, Cabriolet & Tourer 200/400 Coupé, Cabriolet & Tourer Workshop Manual Supplement
Section
Repairs › Blower assembly motor
Heating & ventilationBlower assembly motor

Refit

  1. Fit blower assembly to heater duct and position to body.
  2. Fit and tighten screw securing blower assembly to heater duct.
  3. Fit and tighten nuts securing blower assembly to body.
  4. Fit fascia support panel and tighten bolts to body to 20 Nm.
  5. Fit and tighten bolt securing blower assembly to support panel.
  6. Connect multiplugs to blower assembly.
  7. Fit fascia. See BODY, Interior trim components.
  8. Connect battery earth lead.

BLOWER ASSEMBLY MOTOR

Service repair no - 80.20.15

Remove

  1. Remove blower assembly. See this section.
Blower assembly motor – Remove blower assembly. See this section.
  1. Remove 3 screws securing motor to blower assembly.
  2. Release pipe from motor.
  3. Remove motor from blower assembly.

Refit

  1. Fit motor to blower assembly and secure pipe.
  2. Fit screws securing motor to blower assembly and tighten to 9 Nm.
  3. Fit blower assembly. See this section.
