L322 Range Rover Service Procedures
RESTRAINT SYSTEMS
75-36
REPAIRS
15. Transport deployed airbag module to
designated area for incineration.
CAUTION: Do not re-use or salvage any
parts of the SRS system.
NOTE: Do not transport deployed SRS
components in the vehicle passenger
compartment.
Airbag module - head - rear - deployment
- in vehicle
$% 76.74.44
These guidelines are written to aid authorised
personnel to carry out the safe disposal of airbag
modules.
Deploy
WARNING: It is imperative that before any
work is undertaken on the SRS system, the
appropriate information is read thoroughly.
1. Make the SRS system safe.
Supplementary Restraint System (SRS)
Precautions.
2. Remove headlining.
3. Disconnect multiplug from airbag module.
4. Check condition of deployment tool LRT-86-
003 and associated fly leads.
5. Connect deployment tool fly lead LRT-86-003/
08 to airbag.
