Range Rover P38
ZF AUTO
33
REPAIR
SEAL - VALVE BLOCK - SET
Service repair no - 44.20.13
Remove
1. Remove valve body assembly.
See this
section.
2. Remove circlips and springs from gearbox
casing noting location of long and short springs.
3. Remove and discard seals using LRT-44-005
from gearbox casing.
Refit
4. Clean gearbox casing, springs and circlips.
5. Fit new seals using LRT-44-005, ensure seals
are fully seated.
6. Position springs in their correct locations and
secure with circlips.
7. Fit valve body assembly.
See this section.
