Range Rover P38
ZF AUTO
17
REPAIR
AUTOMATIC GEARBOX - FROM 99MY
Service repair no - 44.20.04.99
Remove
1. Position vehicle on a four post lift.
2. Release fixings from battery cover and remove
cover.
3. Disconnect battery earth lead.
4. Petrol models: Release clips securing cooling
fan cowl and remove cowl.
5. Petrol models: Remove 3 bolts securing engine
RH lifting eye to cylinder head and position earth
strap and lifting eye aside.
6. Diesel Models: Remove starter motor.
See
ELECTRICAL, Repair.
7. Remove window switch pack.
See
ELECTRICAL, Repair.
8. With the handbrake released, remove clip and
clevis pin securing handbrake cable to
handbrake.
9. Raise vehicle and release handbrake cable and
grommet from tunnel.
10. Drain gearbox
See this section. See
LUBRICANTS, FLUIDS AND CAPACITIES,
Information.
11. Drain transfer gearbox fluid.
See SECTION 10,
Maintenance. See LUBRICANTS, FLUIDS
AND CAPACITIES, Information.
12. Petrol models: Remove exhaust front pipe.
See MANIFOLD AND EXHAUST SYSTEM,
Repair.
13. Diesel models: Remove chassis crossmember.
See CHASSIS AND BODY, Repair.
