L322 Range Rover Service Procedures
RESTRAINT SYSTEMS
REPAIRS
75-21
4. Position LRT-86-007/02 in vice, ensuring that
vice jaws grip tool above the bottom flange to
prevent possibility of tool being forced upwards
during detonation. Tighten vice.
5. Fit and secure 2 off LRT-86-007/05 to LRT-86-
007/02.
6. Fit and secure 2 off LRT-86-007/08 to airbag
lower fixing studs.
7. Fit and secure airbag to LRT-86-007/05.
8. Connect deployment tool fly lead LRT-86-003/
05 to airbag.
9. Connect deployment tool LRT-86-003 to
deployment tool fly lead LRT-86-003/05.
10. Connect deployment tool LRT-86-003 to
battery.
WARNING: Ensure all personnel are at least
15 metres (50 feet) away from the airbag
module.
M76 4588
LRT-86-007/08
LRT-86-007/05
M76 4589
M76 4590A
LRT-86-003
LRT-86-003/05
