Exhaust manifold components - KV6 (Manifold & exhaust systems)

Make

Rover

Model

800 Workshop Manual

Year

1996–1999

Section

Description and operation › Exhaust manifold components - KV6

Manifold & exhaust systemsExhaust manifold components - KV6

EXHAUST MANIFOLD COMPONENTS - KV6

1. Exhaust manifold - front (LH)
2. Exhaust manifold - rear (RH)
3. Gasket - exhaust manifold - 2 off
4. Gasket - front to rear manifold
5. Flanged nut - M10 - 8 off
6. Flanged nut - M10 - 2 off
7. Mounting bracket
8. Flange screw - M8 x 12
9. Oxygen sensor
10. Sealing washer
