INLET MANIFOLD COMPONENTS - KV6

1. Inlet manifold - RH
2. Inlet manifold - LH
3. Gasket - inlet manifold - 2 off
4. Flange nut - M8 - 4 off
5. Flange bolt - M8 x 30 - 10 off
6. Gasket - manifold to manifold chamber
7. ’O’ ring - manifold to manifold chamber - 3 off
