Range Rover P38
86
ELECTRICAL
NEW RANGE ROVER
22
REPAIR
AERIAL AMPLIFIER
Service repair no - 86.50.29
Remove
1. Remove parcel tray support panel.
See
CHASSIS AND BODY, Repair.
2. Disconnect 2 multiplugs from amplifier.
3. Release co-axial lead from amplifier.
4. Remove 2 screws securing aerial amplifier to
body.
5. Remove aerial amplifier.
Refit
6. Reverse removal procedure.
AMPLIFIER - DIGITAL SOUND PROCESSING
(DSP) - FROM 2000MY
Service repair no - 86.50.36
Remove
1. Remove LH parcel tray support trim.
See
CHASSIS AND BODY, Repair.
2. Remove sound insulation panel from body.
3. Remove 1 bolt and 2 Allen bolts securing DSP
amplifier to bracket.
