Range Rover P38
ELECTRICAL
11
REPAIR
Refit
10. Ensure mating faces are clean.
11. Position starter motor. Locate onto dowel.
12. Align fluid pipe bracket. Secure starter motor
with nuts and bolts. Tighten to
48 Nm.
(35 lbf.ft).
13. Tighten clutch fluid pipe bracket lower bolt to
86 Nm (63 lbf.ft).
INDICATOR STALK
Service repair no - 86.65.64
Remove
1. Remove steering column nacelle.
See
STEERING, Repair.
2. Disconnect multiplug from stalk.
3. Remove 2 screws securing stalk to steering
column.
4. Remove indicator stalk.
Refit
5. Reverse removal procedure.
