Land Rover Range Rover P38 Service and Repair Manuals

86

ELECTRICAL

NEW RANGE ROVER

14

REPAIR

ULTRASONIC SENSOR

Service repair no - 86.55.96

Remove

1. Release ultrasonic sensor from headlining.
2. Disconnect multiplug. Remove sensor.

Refit

3. Reverse removal procedure.

RECEIVER

Service repair no - 86.55.38

Remove

1. Remove RH parcel shelf support trim.

See

CHASSIS AND BODY, Repair.

2. Disconnect Lucar and multiplug from receiver.
3. Remove screw. Remove receiver.

Refit

4. Reverse removal procedure.
