Range Rover P38
ELECTRICAL
43
REPAIR
WINDOW MOTOR - REAR DOOR
Service repair no - 86.25.09
Remove
1. Remove rear window motor control panel.
See
this section.
2. Remove 3 screws securing motor to control
panel. Remove motor.
Refit
3. Ensure window lift control gear and motor
support are clean. Grease moving parts.
4. Reverse removal procedure.
FASCIA HARNESS - VEHICLES WITH SINGLE
POINT SENSED SRS
Service repair no - 86.70.10
Remove
1. Remove fascia assembly.
See CHASSIS AND
BODY, Repair.
2. Remove passenger airbag module.
See
SUPPLEMENTARY RESTRAINT SYSTEM,
Repair.
3. Remove 2 nuts securing passenger side heater
blower unit to fascia.
4. Release blower unit from fascia and heater duct.
5. Disconnect 3 multiplugs and 1 Lucar from blower
unit.
6. Remove passenger blower unit.
