Range Rover P38
ELECTRICAL
15
REPAIR
SWITCH TAILGATE RELEASE
Service repair no - 86.26.26
Remove
1. Release 3 studs securing tailgate board.
Remove board.
2. Disconnect tailgate switch multiplug.
3. Remove 2 screws securing switch to tailgate.
4. Turn switch clockwise to remove.
Refit
5. Reverse removal procedure.
TAILGATE SOLENOID
Service repair no - 86.26.02
Remove
1. Release studs securing tailgate board. Remove
board.
2. Release solenoid operating rod from tailgate
latch.
3. Remove 3 screws securing solenoid assembly.
4. Disconnect multiplug. Remove solenoid.
