Range Rover P38
ELECTRICAL
13
REPAIR
6. Lift 2 clips securing each switch pack. Remove
switch packs and printed circuit assembly.
Refit
7. Reverse removal procedure.
ELECTRIC WINDOW SWITCH PACK
Service repair no - 86.25.08
Remove
1. Remove 2 screws securing switch pack to centre
console.
2. Release switch pack. Disconnect multiplug.
3. Withdraw gaiter over handbrake. Remove switch
pack.
Refit
4. Reverse removal procedure.
