HIGH LEVEL STOP LAMP
Service repair no - 86.41.32
NOTE: An access panel is provided in the
upper tailgate trim panel to allow bulb
replacement.
Remove
1. Remove lower trim panel assembly from upper
tailgate.
2. Remove rubber finisher from panel assembly.
3. Release 6 lugs securing halves of trim panel
assembly.
4. Separate finisher halves.
5. Remove 4 screws securing stop lamp assembly
to upper trim half.
6. Remove stop lamp assembly.
Refit
7. Position stop lamp assembly and secure with
screws.
8. Fit rubber finisher to upper trim half.
9. Fit trim halves together and engage lugs.
10. Fit lower trim panel assembly to upper tailgate.
TAIL LAMP
Service repair no - 86.40.70
Remove
1. Release 2 studs securing rear speaker resonator
cover. Release cover.
2. Remove tail lamp access cover.
