Rover Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition18 · Electrical
18 · Electrical

Battery (page 2 of 2)

Make
Rover
Model
600 Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition
Section
Wire harness and earth locations
ElectricalBattery · page 2 of 2
Schematic diagram of the under-hood fuse/relay box showing connections for condenser fan motor, radiator fan control module, PGM-FI main relay, power seat motor, engine control module, transmission control module, clock, stereo radio/cassette player, and power window relay circuits. Includes labels for fuses No.30 through No.39, wire colors, and ground G201. Also shows key-off operation control unit connections for systems with and without key-off operation.
UNDER-HOOD FUSE/RELAY BOX (From page 23-43) A No.30 (15A) — WHT — Condenser fan motor / Radiator fan control module No.31 (10A) — YEL/BLU — PGM-FI main relay (+B) No.32 (20A) — WHT/RED — Power seat up-down motor No.35 (7.5A) — WHT/YEL — Engine control module (ECM) / Transmission control module (TCM) / Clock (+B) / Stereo radio/cassette player POWER WINDOW RELAY No.39 (20A) — WHT/YEL — Master power window switch / Right front power window motor / Key-off operation control unit No.38 (20A) — BLU/BLK — Left front power window motor / Key-off operation control unit No.37 (20A) — YEL/BLK — Right rear power window motor / Key-off operation control unit No.36 (20A) — GRN/BLK — Left rear power window motor / Key-off operation control unit (Without key-off operation system) No.5 (7.5A) FUSE (From page 23-48) — [16] — YEL/GRN — BLK — G201 KEY-OFF OPERATION CONTROL UNIT — [YEL/GRN] — (To page 23-45) B (With key-off operation system) 86M 1959
