Rover 400 Workshop Manual (1995-2000)10 · Engine management system - MEMS
10 · Engine

Intake air temperature sensor - ’t’ series

Make
Rover
Model
400 Workshop Manual
Year
1995–2000
Section
Repairs › Intake air temperature sensor - ’t’ series
Engine management system - MEMSIntake air temperature sensor - ’t’ series

Refit

  1. Position relay module and connect multiplugs.
  2. Align relay module and secure to mounting bracket.
  3. Fit engine control module. See this section.

INTAKE AIR TEMPERATURE SENSOR - ’T’ SERIES

Service repair no - 18.30.09

Remove

  1. Disconnect battery earth lead.
Intake air temperature sensor - ’t’ series – Disconnect battery earth lead.
  1. Disconnect multiplug from sensor.
  2. Remove sensor from inlet manifold.
  3. Remove sealing washer from sensor.

Refit

  1. Clean sensor and manifold mating faces.
  2. Fit NEW sealing washer to sensor.
  3. Fit sensor to intake manifold and tighten to 7 Nm.
  4. Connect multiplug to sensor.
  5. Connect battery earth lead.
