Rover Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition16 · Body
16 · Body & interior

Replacement

Make
Rover
Model
600 Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition
Section
Interior fittings › Replacement
BodyReplacement

Replacement

Diagram showing the rearview mirror assembly with callouts A and B
  • A Mirror fixing slug
  • B Rearview mirror
Diagram showing the pivot bracket and rearview mirror assembly with callouts A and B
  • A Pivot bracket
  • B Rearview mirror

Note: Take care not to scratch the windshield.

  1. Carefully slide up the rearview mirror pivot bracket from the slug.
  2. Install the rearview mirror, heat the pivot and mirror side with a low powered heater gun for several minutes.
