Range Rover P38
86
ELECTRICAL
NEW RANGE ROVER
52
REPAIR
35. Remove bolt securing engine harness ’P’ clip to
rear of LH cylinder head.
36. Remove cable tie securing purge pipe to engine
rear lifting eye.
37. Models with automatic gearbox: Remove
window switch pack.
See this section.
38. Models with manual gearbox: Remove centre
console.
See CHASSIS AND BODY, Repair.
39. Models with manual gearbox: Remove 6 nuts
securing gear lever gaiter ring and remove gaiter
ring and gaiter.
40. Models with manual gearbox: Remove 2 bolts
securing gear lever and remove lever.
41. With handbrake released, remove clip and clevis
pin securing handbrake cable to handbrake.
42. Remove chassis crossmember.
See CHASSIS
AND BODY, Repair.
