Refit bonnet lock

Refit BONNET LOCK

12. With assistance, position rear headlining to roof Service repair no - 76.16.21 and locate rear corners in cant rail.
13. Push headlining rearwards and position over Remove rear end lining mounting brackets.
14. Locate front corners of headlining in cant rail.
15. Position front edge of rear headlining over front headlining and secure with trim studs.
16. Adjust rear headlining to achieve good fit at all corners.
17. Fit rear interior lamp. See ELECTRICAL, Repair, Interior lamp
18. Fit interior roll-over bar. See Interior roll-over bar - hard top
19. Fit rear end lining. See Rear end lining - hard top
20. Fit rear grab handles. See Rear grab handle - hard top
21. Fit side trim panels. See Side trim panel - hard top
22. Fit rear end trim panels. See Rear end trim panel - hard top

Refit

10. Fit spring between lock and bonnet platform.
11. Position lock and guide plate to bonnet platform
12. Position guide plate and lock to position marks
13. Fit cable to lock and tighten clamping bolt.
14. Check operation of release cable and adjust if
15. Fit grille and tighten securing screws.
16. Close bonnet.
1. Open bonnet.

2. Mark position of guide plate and lock to bonnet platform.
3. Remove 8 screws securing grille.
4. Remove grille.
5. Remove 2 bolts securing guide plate and lock.
6. Remove guide plate.
7. Release spring securing lock to bonnet platform.
8. Slacken clamping bolt securing bonnet release cable.
9. Remove lock.

and nip up bolts.

and tighten bolts to 10 Nm. 7 lbf/ft.

necessary.
