LIGHTING

86-2-8

REPAIRS

Lamp assembly - glove compartment

$% 86.45.08

Remove

1. Open glove box.

2. Release illumination lamp from glove box.
3. Disconnect 2 Lucars and remove glove box

lamp.

Refit

1. Position lamp and connect Lucars.
2. Fit lamp and close glove box.

Lamp assembly - load space

$% 86.45.16

Remove

1. Release load space lamp from trim casing.
2. Disconnect 2 Lucars and remove load space

lamp.

Refit

1. Position lamp and connect Lucars.
2. Fit load space lamp to trim casing.
