Freelander Service Procedures
ENGINE - K SERIES KV6
12-3-98 OVERHAUL
13. Check cylinder head face for warping, across
centre and from corner to corner.
14. Check cylinder head height.
Note: Provided that cylinder head height is kept
within limits, cylinder heads may be refaced.
15. Check condition of valve springs and measure
16. Remove carbon deposits from exhaust valve
guides using a 6 mm diameter reamer inserted
from combustion side of cylinder head.
17. Remove carbon from inlet valve guides, inlet
and exhaust valves and valve seat inserts.
Remove all loose carbon on completion.
18. Check and record existing valve stem
diameters 'A', replace any valve with stem
diameter less than specified.
19. Check inlet and exhaust valve to guide
clearances 'B' using the following procedures.
