Freelander Service Procedures
INSTRUMENTS
REPAIRS
88-5
Cowl - instrument - from 04MY
$% 88.20.02
Remove
1. Release 5 clips securing steering column
nacelle gaiter to the instrument cowl. Remove
gaiter for access to screws.
2. Remove 6 screws securing instrument cowl to
fascia.
3. Release instrument cowl from fascia,
disconnect multiplugs and remove assembly.
NOTE: Do not carry out further dismantling if
component is removed for access only.
4. Remove switches and switch blanks from cowl.
Refit
1. Fit switches and switch blanks to cowl.
2. Fit steering column gaiter to instrument cowl.
3. Position cowl and connect multiplugs to
switches.
4. Fit cowl and tighten screws.
5. Fit and secure steering column gaiter to
nacelle.
M88 0363
