Front bulkhead

FRONT BULKHEAD

Description

The front bulkhead is joined to the front inner wing and front side frame. It forms the base for the headlights and other parts and maintains the rigidity of the front section of the body. Pay particular attention to twists and parallelism and check mounting of related parts when welding.

Mass Production Body Welding Diagram - plan view

A. Bulkhead Upper Frame and Centre Stay/Bonnet latch bracket B. Bulkhead upper frame and Front side bulkhead C. Front side frame D. Front inner wing E. Bulkhead upper frame and Front inner wing
