Rover Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition16 · Body
16 · Body & interior

Front Bumper Replacement (page 4 of 4)

Make
Rover
Model
600 Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition
Section
Exterior fittings
BodyFront Bumper Replacement · page 4 of 4
  1. Open the boot.
  2. Remove clips from locations shown by white triangles.
  3. Remove screws and bolts from locations shown by black triangles.
  4. Remove main bumper mounting nuts from boot locations shown by black circles.

Note:

  • Use an assistant when removing and refitting the rear bumper.
  • Take care not to scratch the rear bumper.
  • If necessary, replace the rear bumper beam.
  1. Installation is the reverse of the removal procedure.
Diagram showing rear bumper mounting points with white triangles, black triangles, and black circles indicating clip, screw/bolt, and nut locations respectively.
