Console - rear

INTERIOR TRIM COMPONENTS

76-3-12 REPAIRS

Console - rear

$% 76.25.04

Remove

1. Release rear ash tray panel from rear console,

disconnect multiplug from power socket and
remove panel.

2. Remove oddments tray liner, raise cubby box

lid and remove cubby box.

3. Remove 2 screws securing rear of console.
4. Remove screw cover and remove 2 screws

securing front of console.

5. Disconnect multiplugs from window lift switches

and if fitted, rear window isolator switch.
